DZL Series Compact Steam Boiler
Product thermal capacity: 2-10 t/h
Working pressure: 1-2.5 MPa
Available fuel: Biomass molding granules, wood chip, corn cob, saw dust, palm shells, rice husk, etc.
Available industries: Heating, chemical, food, tobacco, textile, printing and dyeing, feed, medicine, building material, wine, rubber, hospital.
DZL Series Compact Steam Boiler Introduction
The DZL series compact steam boiler is an efficient and energy-saving industrial boiler with a compact structure and easy installation, suitable for a wide range of industrial applications. This series features advanced grate design, which effectively reduces fuel consumption and improves combustion efficiency. The boiler achieves thermal efficiency of over 83%, fully utilizing the calorific value of biomass fuels and reducing operating costs.
The compact design of the DZL series steam boiler allows for a smaller footprint and easy installation, making it ideal for industrial environments with limited space. The DZL series compact steam boiler is equipped with an automatic control system that continuously monitors the boiler’s operating status, ensuring it runs under optimal conditions. Additionally, high-quality insulation materials are used within the boiler to minimize heat loss and further enhance energy efficiency.
DZL Series Compact Steam Boiler Advantages
Energy-Efficient and Cost-Effective: The DZL series compact steam boiler features advanced chain grate design and efficient heat exchange systems, achieving thermal efficiency of over 83%. The boiler maximizes fuel utilization, reduces energy waste, and lowers operational costs for businesses.
Easy Operation: The DZL series compact steam boiler features an advanced control system with a high degree of automation for fuel supply, ash removal, and slag disposal, ensuring simplified operation.
Flexible Fuel Adaptability: The DZL series compact steam boiler can accommodate a variety of biomass fuels, meeting the diverse needs of different users.
Convenient Installation: With its compact structure, the DZL series compact steam boiler is easy to install on-site, requires a short installation period, and helps reduce infrastructure investment.
DZL Series Compact Steam Boiler Specification
| Model | Rated thermal power (t/h) | Rated working pressure (MPa) | Rated steam temperature (℃) | Maximum transport dimension (m) |
| DZL2-1.25-SCⅢ | 2 | 1.25 | 194 | 5.30×2.40×3.40 |
| DZL2-1.6-SCⅢ | 2 | 1.6 | 204 | 5.30×2.40×3.40 |
| DZL2-2.5-SCⅢ | 2 | 2.5 | 225 | 5.30×2.40×3.40 |
| DZL4-1.25-SCⅢ | 4 | 1.25 | 194 | 6.50×2.70×3.60 |
| DZL4-1.6-SCⅢ | 4 | 1.6 | 204 | 6.50×2.70×3.60 |
| DZL4-2.5-SCⅢ | 4 | 2.5 | 225 | 6.50×2.70×3.60 |
