YLW Series Coal/Biomass Fired Thermal Fluid Heater

Product Thermal Capacity:1400-29000 KW
Working Pressure: 0.8-1.0 MPA
Available Fuel: Bituminous coal, anthracite, biomass particles
Available Industries: Chemical,high temperature heating technology for fertilizer, melamine, alumina and so on
Coal/Biomass Fired Thermal Fluid Heater Advantages
Digitized manufacture
- The laying-off of steel tube adopts CNC 3D laser cutting machine.
- The manufacture of square coil tube adopts CNC three-dimensional tube bending machine, no forced shaping.
- The manufacture of serpentuator adopts serpentuator automatic production line, once-forming.
Full argon arc welding
YLW series thermal fuid heater adopt square coil tube and coil tube all adopt argon arc welding technique,which guarantees tubes are 100% qualified.
Long life span
- The optimized radiation heating surface and convective heating surface, the medium flow is more reasonable, without overheat of the carrier and reduce the life;
- Convection section: optimize convection heating surface and adopt effective fix and structural support to make its working life longer.
- Set up effective flue gas partition for convection heating surface and cast partition to make it works longer.
Easy operation
- We have combustion arch patent, which is available for different types of coals, even the anthracite is very easy to burn.
- Flame-proof feeding bucket can avoid the feeding bucket is burnt and coking.
- There is ash cleaning unit, which is easy for maintaining, operating and cleaning.
Less fuel consumption
- Use superior refractory brick to build inside and superior perlite in the middle. Keep the furnace temperature under 50℃ to make the minimization of loss.
- Furnace adopts double close line coil, which makes heating surface sufficient.
YLW Series Thermal Fluid Heater Specification
Model | Rated thermal power (KW) | Rated thermal power (x104kcal/h) | Design working temperature(≤℃) | Rated working pressure(MPa) | Thermal efficiency(≥%) | System installation power(KW) | Maximum transport size(m) (L×W×H) |
YLW-1400M/AⅡ | 1400 | 120 | 320 | 0.8 | 80 | 55 | 5.0×2.3×2.5 |
YLW-1800M/AⅡ | 1800 | 160 | 320 | 0.8 | 80 | 63 | 5.6×2.3×2.8 |
YLW-2400M/AⅡ | 2400 | 200 | 320 | 0.8 | 80 | 76 | 6.5×2.5×2.8 |
YLW-2800M/AⅡ | 2800 | 240 | 300 | 0.8 | 80 | 85 | 6.5×2.6×3.2 |
YLW-3500M/AⅡ | 3500 | 300 | 320 | 0.8 | 80 | 105 | 7.5×2.6×3.2 |
YLW-4200M/AⅡ | 4200 | 360 | 320 | 0.8 | 80 | 125 | 7.4×2.9×3.3 |
YLW-4600M/AⅡ | 6000 | 500 | 320 | 0.8 | 80 | 155 | 8.4×3.4×3.3 |
YLW-6000M/AⅡ | 7000 | 600 | 320 | 1 | 80 | 170 | 9.0×3.4×3.4 |
YLW-7000M/AⅡ | 8200 | 700 | 320 | 1 | 80 | 193 | 9.8×3.3×4.1 |
YLW-8200M/AⅡ | 4600 | 400 | 320 | 1 | 80 | 150 | 8.0×2.9×3.4 |
YLW-9400M/AⅡ | 9400 | 800 | 320 | 1 | 80 | 160 | 9.8×3.5×4.1 |
YLW-10500M/AⅡ | 10500 | 900 | 320 | 1 | 80 | 160 | 10.5×3.5×4.1 |
YLW-12000M/AⅡ | 12000 | 1000 | 320 | 1 | 80 | 260 | 11.2×3.6×4.1 |
YLW-14000M/AⅡ | 14000 | 1200 | 320 | 1 | 80 | 320 | 10.5×4.0×3.5 |
YLW-16500M/AⅡ | 16500 | 1400 | 320 | 1 | 80 | 380 | 11.5×4.3×3.5 |
YLW-18000M/AⅡ | 18000 | 1600 | 320 | 1 | 80 | 450 | 11.5×4.5×3.5 |
YLW-21000M/AⅡ | 21000 | 1800 | 320 | 1 | 81 | 520 | 11.5×4.5×3.9 |
YLW-23300M/AⅡ | 23300 | 2000 | 320 | 1 | 81 | 600 | 11.5×3.0×4.0 |
YLW-26000M/AⅡ | 26000 | 2200 | 320 | 1 | 81 | 700 | 11.5×3.0×4.0 |
YLW-29200M/AⅡ | 29200 | 2500 | 320 | 1 | 81 | 825 | 12.0×3.3×4.2 |
