SZL Series Chain Grate Coal Boilers for Sale

ZOZEN Coal Boilers for Sale

Product thermal capacity: 6-35 t/h

Working pressure: 1-2.5 MPa

Available fuel: Bituminous coal, lean coal, anthracite

Available industries: Heating, chemical, food, tobacco, textile, print and dyeing, feed, medicine, building materials, wine, hospital

SZL Series Chain Grate Coal Boilers for Sale Introduction

The SZL series chain grate coal boilers for sale utilize chain grate technology, ensuring complete combustion of coal and high thermal efficiency. The rational design of the grate structure promotes stable combustion, resulting in high coal utilization and reduced fuel consumption costs. This series of boilers are adaptable to various types of coal, offering great flexibility. With an advanced control system, they operate automatically and boast high reliability. Additionally, multiple safety protection devices are incorporated to ensure safe operation. The boilers employ advanced combustion technology and exhaust gas treatment equipment, reducing emissions of nitrogen oxides and particulate matter. They feature efficient heat conversion and heat recovery systems, enhancing energy utilization efficiency and minimizing environmental impact.

SZL Series Chain Grate Coal Boilers for Sale Features

Broad Fuel Adaptability: It can accommodate various types of coal, including bituminous coal, sub-bituminous coal, and anthracite, ensuring wide fuel adaptability.

Complete Fuel Combustion: The well-designed chain grate and independent air chamber ensure thorough fuel combustion, maximizing fuel utilization.

Thermal Efficiency >80%: The furnace is equipped with densely arranged water-cooled wall tubes, providing a large radiation surface area and achieving high thermal efficiency.

Easy Operation and Maintenance: With an advanced control system, the boiler offers automated fuel supply, ash removal, and slag discharge, simplifying operation and maintenance tasks.

SZL Series Chain Grate Coal Boilers for Sale Specification

Model Rated steam capacity (t/h) Rated working pressure (MPa) Rated steam temperature (℃) Maximum transport dimension (m)
SZL6-1.25-AⅡ 6 1.25 194 6.20×2.80×3.65
7.40×2.70×2.40
SZL6-1.6-AⅡ 6 1.6 204 6.20×2.80×3.65
7.40×2.70×2.40
SZL6-2.5-AⅡ 6 2.5 225 6.20×2.80×3.65
7.40×2.70×2.40
SZL8-1.25-AⅡ 8 1.25 194 7.80×3.25×3.61
8.25×3.10×2.80
SZL8-1.6-AⅡ 8 1.6 204 7.80×3.25×3.61
8.25×3.10×2.80
SZL8-2.5-AⅡ 8 2.5 225 7.80×3.25×3.61
8.25×3.10×2.80
SZL10-1.25-AⅡ 10 1.25 194 7.80×3.25×3.61
9.00×3.10×2.80
SZL10-1.6-AⅡ 10 1.6 204 7.80×3.25×3.61
9.00×3.10×2.80
SZL10-2.5-AⅡ 10 2.5 225 7.80×3.25×3.61
9.00×3.10×2.80
SZL12-1.25-AⅡ 12 1.25 194 8.80×3.52×3.65
8.40×3.10×2.80
SZL12-1.6-AⅡ 12 1.6 204 8.80×3.52×3.65
8.40×3.10×2.80
SZL12-2.5-AⅡ 12 2.5 225 8.80×3.52×3.65
8.40×3.10×2.80
SZL15-1.25-AⅡ 15 1.25 194 9.65×3.28×3.60
10.70×3.30×2.80
SZL15-1.6-AⅡ 15 1.6 204 9.65×3.28×3.60
10.70×3.30×2.80
SZL15-2.5-AⅡ 15 2.5 225 9.65×3.28×3.60
10.70×3.30×2.80
SZL20-1.25-AⅡ 20 1.25 194 10.65×3.28×3.60
10.30×3.81×2.80
SZL20-1.6-AⅡ 20 1.6 204 10.65×3.28×3.60
10.30×3.81×2.80
SZL20-2.5-AⅡ 20 2.5 225 10.65×3.28×3.60
10.30×3.81×2.80
SZL25-1.25-AⅡ 25 1.25 194 11.65×3.80×3.60
10.30×3.81×2.80
SZL25-1.6-AⅡ 25 1.6 204 11.65×3.80×3.60
10.30×3.81×2.80
SZL25-2.5-AⅡ 25 2.5 225 11.65×3.80×3.60
10.30×3.81×2.80
SZL30-1.25-AⅡ 30 1.25 194 10.00×3.36×3.60
SZL30-1.6-AⅡ 30 1.6 204 10.00×3.36×3.60
SZL30-2.5-AⅡ 30 2.5 225 10.00×3.36×3.60
SZL35-1.25-AⅡ 35 1.25 194 10.00×3.65×3.85
SZL35-1.6-AⅡ 35 1.6 204 10.00×3.65×3.85
SZL35-2.5-AⅡ 35 2.5 225 10.00×3.65×3.85
