WNS Series Automatic Steam Boiler
Product thermal capacity: 1 – 20 t/h
Working pressure: 0.7-2 MPa
Available fuel: Natural gas, coke oven gas, biogas, diesel, heavy oil, light oil, crude oil, etc.
Available industries: Heat supplying, chemical, food, textile, printing and dyeing, cigarettes and tobacco, fodder, pharmacy, building materials, brewery, rubber, hospital etc.
WNS Series Automatic Steam Boiler Introduction
The WNS series automatic steam boiler features a horizontal structure and is equipped with an automated control system, enabling fully automated operation that greatly enhances operational convenience and safety. The heating system of the WNS series automatic steam boiler utilizes a high-efficiency burner, significantly reducing energy consumption while ensuring steam quality. This boiler is designed to meet international environmental standards, with minimal pollutant emissions that comply with various environmental regulations. It is equipped with an advanced control system that allows real-time monitoring of the boiler’s operating status, including temperature, pressure, and water level, ensuring the boiler operates at optimal conditions. Users can operate it remotely, simplifying management processes and improving overall efficiency.
WNS Series Automatic Steam Boiler Advantages
High Efficiency and Energy Saving: The WNS series automatic steam boiler employs internationally leading combustion technology and an optimized heat exchange system, achieving a thermal efficiency of over 98%, significantly reducing operational costs.
Intelligent Control: The WNS series automatic steam boiler is equipped with an advanced PLC control system that monitors the boiler’s operating status in real time, enabling automated control and remote monitoring to ensure safe and reliable operation.
Compact Structure: The overall design of the WNS series automatic steam boiler is compact, occupying a small footprint, making it easy to install and suitable for various industrial sites.
Environmental Compliance: The WNS series automatic steam boiler utilizes low nitrogen combustion technology, resulting in low nitrogen oxide emissions that comply with national environmental standards.
Safety Assurance: The WNS series automatic steam boiler is equipped with multiple safety protection devices, including over-temperature and over-pressure protection, ensuring safe operation of the boiler.
WNS Series Automatic Steam Boiler Specification
| Model | Rated steam capacity (t/h) | Rated working pressure (MPa) | Rated steam temperature (℃) | Maximum transport weight (t) | Maximum transport dimension (m) |
| WNS1-0.7-Q(Y) | 1 | 0.7 | 170 | 4.5 | 3.25×1.80×2.00 |
| WNS1-1.0-Q(Y) | 1 | 1 | 184 | 4.5 | 3.25×1.80×2.00 |
| WNS1.5-1.0-Q(Y) | 1.5 | 1 | 184 | 7 | 3.65×2.05×2.45 |
| WNS1.5-1.25-Q(Y) | 1.5 | 1.25 | 194 | 7 | 3.65×2.05×2.45 |
| WNS2-1.0-Q(Y) | 2 | 1 | 184 | 9 | 4.60×2.20×2.60 |
| WNS2-1.25-Q(Y) | 2 | 1.25 | 194 | 9 | 4.60×2.20×2.60 |
| WNS3-1.0-Q(Y) | 3 | 1 | 184 | 11.5 | 5.35×2.40×2.80 |
| WNS3-1.25-Q(Y) | 3 | 1.25 | 194 | 11.5 | 5.35×2.40×2.80 |
| WNS4-1.25-Q(Y) | 4 | 1.25 | 194 | 15 | 5.00×2.60×2.95 |
| WNS4-1.6-Q(Y) | 4 | 1.6 | 204 | 15 | 5.00×2.60×2.95 |
| WNS5-1.25-Q(Y) | 5 | 1.25 | 194 | 18 | 5.55×2.658×3.20 |
| WNS5-1.6-Q(Y) | 5 | 1.6 | 204 | 18 | 5.55×2.658×3.20 |
| WNS6-1.25-Q(Y) | 6 | 1.25 | 194 | 19.5 | 5.93×2.80×3.20 |
| WNS6-1.6-Q(Y) | 6 | 1.6 | 204 | 19.5 | 5.93×2.80×3.20 |
| WNS8-1.25-Q(Y) | 8 | 1.25 | 194 | 25 | 7.00×2.80×3.25 |
| WNS8-1.6-Q(Y) | 8 | 1.6 | 204 | 25 | 7.00×2.80×3.25 |
| WNS10-1.25-Q(Y) | 10 | 1.25 | 194 | 27.5 | 7.65×2.80×3.25 |
| WNS10-1.6-Q(Y) | 10 | 1.6 | 204 | 27.5 | 7.65×2.80×3.25 |
| WNS15-1.25-Q(Y) | 15 | 1.25 | 194 | 40 | 7.95×3.50×3.75 |
| WNS15-1.6-Q(Y) | 15 | 1.6 | 204 | 40 | 7.95×3.50×3.75 |
| WNS20-1.25-Q(Y) | 20 | 1.25 | 194 | 52 | 8.55×3.90×4.15 |
| WNS20-1.6-Q(Y) | 20 | 1.6 | 204 | 52 | 8.55×3.90×4.15 |
