DZL Series Coal Fired Steam Boiler for Sale

ZOZEN Coal Fired Steam Boiler for Sale

Product thermal capacity: 2-10 t/h

Working pressure: 1-2.5 MPa

Available fuel: Bituminous coal,lean coal,anthracite

Available industries: Heating, chemical, food, tobacco, textile, printing and dyeing, feed, medicine, building material, wine, rubber, hospital

DZL Series Coal Fired Steam Boiler for Sale Introduction

The DZL Series Coal Fired Steam Boiler for Sale utilizes specially designed furnace grates to ensure smooth operation of the grates. The auxiliary combustion air system (base) adopts independent compartments and a scientifically sealed structure. The rational air regulation device achieves precise air distribution, thereby improving combustion efficiency. The advanced combustion system maximizes coal combustion efficiency, reducing fuel consumption and emissions.

The DZL Series Coal Fired Steam Boiler for Sale has lower operating costs, nearly 50% lower than boilers using oil or natural gas. Combined with our proven high-efficiency, low-emission clean coal technology, our coal-fired boilers offer sufficient output, high thermal efficiency, and wide coal adaptability without compromising safety and reliability.

DZL Series Coal Fired Steam Boiler for Sale Features

High Efficiency and Energy Saving: This boiler adopts advanced combustion technology and design, maximizing coal combustion efficiency and reducing fuel consumption and energy waste. It efficiently converts coal into steam energy, achieving effective utilization and conservation of energy.

Environmental Protection and Purification: The DZL Series boiler is equipped with advanced coal purification devices that minimize the emission of harmful gases and particulate matter during the combustion process. With its efficient combustion chamber and flue design, the emission of flue gases is cleaner, resulting in minimal impact on the environment.

User-Friendly Operation: The advanced control system of the boiler ensures high automation levels for fuel supply, ash removal, and slag discharge operations, making it easy to operate.

Reliable and Stable: The DZL Series boiler features a compact structure and high-quality manufacturing, ensuring reliable performance and longevity. It undergoes strict quality control and testing, exhibiting outstanding stability and durability.

DZL Series Coal Fired Steam Boiler for Sale Specification

Model Rated steam capacity (t/h) Rated working pressure (MPa) Rated steam temperature (℃) Thermal efficiency (%) Maximum transport dimension (m)
DZL2-1.25-AⅡ 2 1.25 194 >80 5.30×2.40×3.40
DZL2-1.6-AⅡ 2 1.6 204 >80 5.30×2.40×3.40
DZL2-2.5-AⅡ 2 2.5 225 >80 5.30×2.40×3.40
DZL4-1.25-AⅡ 4 1.25 194 >80 6.50×2.70×3.60
DZL4-1.6-AⅡ 4 1.6 204 >80 6.50×2.70×3.60
DZL4-2.5-AⅡ 4 2.5 225 >80 6.50×2.70×3.60
