WNS Series 6 Ton Gas Boiler
Product thermal capacity: 1 – 20 t/h
Working pressure: 0.7-2 MPa
Available fuel: Natural gas, coke oven gas, biogas, diesel, heavy oil, light oil, crude oil, etc.
Available industries: Heat supplying, chemical, food, textile, printing and dyeing, cigarettes and tobacco, fodder, pharmacy, building materials, brewery, rubber, hospital etc.
WNS Series 6 Ton Gas Boiler Introduction
The WNS series 6 ton gas boiler adopts advanced combustion technology and design, offering excellent performance and stable operation. This boiler uses gas as fuel and features an efficient combustion system to meet the thermal energy needs of industrial production. Additionally, the WNS series 6 ton gas boiler is equipped with an advanced control system, enabling automated operation, improving production efficiency, and reducing manual intervention.
The WNS series 6 ton gas boiler has a compact design with a small footprint, making it ideal for installation in limited spaces such as factories. Its structure is robust and durable, with simple operation and easy maintenance, effectively extending the service life of the equipment.
WNS Series 6 Ton Gas Boiler Advantages
High Efficiency and Energy Saving: The WNS series 6 ton gas boiler employs a corrugated furnace and threaded smoke tubes design, achieving a thermal efficiency of up to 98%, greatly reducing energy consumption and operational costs. The optimized heat exchange system enhances thermal energy utilization efficiency and effectively reduces heat loss.
Superior Environmental Performance: The WNS series 6 ton gas boiler uses low-nitrogen combustion technology, effectively reducing nitrogen oxide (NOx) emissions, and complies with stringent environmental standards both domestically and internationally. Its low emission features make it an ideal choice for eco-friendly industrial boilers.
Safety Assurance: The boiler design strictly follows international safety standards and is equipped with multiple safety protection devices, such as water level, high and low-pressure protection, and overheat protection, effectively preventing equipment failure and ensuring safe and reliable operation of the boiler.
Compact Structure: The WNS series 6 ton gas boiler has a compact structure, small installation area, and is easy to install and maintain, making it suitable for installation in limited spaces such as factories.
WWNS Series 6 Ton Gas Boiler Specification
| Model | Rated steam capacity (t/h) | Rated working pressure (MPa) | Rated steam temperature (℃) | Maximum transport weight (t) | Maximum transport dimension (m) |
| WNS1-0.7-Q(Y) | 1 | 0.7 | 170 | 4.5 | 3.25×1.80×2.00 |
| WNS1-1.0-Q(Y) | 1 | 1 | 184 | 4.5 | 3.25×1.80×2.00 |
| WNS1.5-1.0-Q(Y) | 1.5 | 1 | 184 | 7 | 3.65×2.05×2.45 |
| WNS1.5-1.25-Q(Y) | 1.5 | 1.25 | 194 | 7 | 3.65×2.05×2.45 |
| WNS2-1.0-Q(Y) | 2 | 1 | 184 | 9 | 4.60×2.20×2.60 |
| WNS2-1.25-Q(Y) | 2 | 1.25 | 194 | 9 | 4.60×2.20×2.60 |
| WNS3-1.0-Q(Y) | 3 | 1 | 184 | 11.5 | 5.35×2.40×2.80 |
| WNS3-1.25-Q(Y) | 3 | 1.25 | 194 | 11.5 | 5.35×2.40×2.80 |
| WNS4-1.25-Q(Y) | 4 | 1.25 | 194 | 15 | 5.00×2.60×2.95 |
| WNS4-1.6-Q(Y) | 4 | 1.6 | 204 | 15 | 5.00×2.60×2.95 |
| WNS5-1.25-Q(Y) | 5 | 1.25 | 194 | 18 | 5.55×2.658×3.20 |
| WNS5-1.6-Q(Y) | 5 | 1.6 | 204 | 18 | 5.55×2.658×3.20 |
| WNS6-1.25-Q(Y) | 6 | 1.25 | 194 | 19.5 | 5.93×2.80×3.20 |
| WNS6-1.6-Q(Y) | 6 | 1.6 | 204 | 19.5 | 5.93×2.80×3.20 |
| WNS8-1.25-Q(Y) | 8 | 1.25 | 194 | 25 | 7.00×2.80×3.25 |
| WNS8-1.6-Q(Y) | 8 | 1.6 | 204 | 25 | 7.00×2.80×3.25 |
| WNS10-1.25-Q(Y) | 10 | 1.25 | 194 | 27.5 | 7.65×2.80×3.25 |
| WNS10-1.6-Q(Y) | 10 | 1.6 | 204 | 27.5 | 7.65×2.80×3.25 |
| WNS15-1.25-Q(Y) | 15 | 1.25 | 194 | 40 | 7.95×3.50×3.75 |
| WNS15-1.6-Q(Y) | 15 | 1.6 | 204 | 40 | 7.95×3.50×3.75 |
| WNS20-1.25-Q(Y) | 20 | 1.25 | 194 | 52 | 8.55×3.90×4.15 |
| WNS20-1.6-Q(Y) | 20 | 1.6 | 204 | 52 | 8.55×3.90×4.15 |
