SZL Series Wood Chip Pellet Boiler

ZOZEN Wood Chip Pellet Boiler

Product thermal capacity: 6-35 t/h

Working pressure: 1-2.5 MPa

Available fuel: Biomass molding granules, wood chip, corn cob, saw dust, palm shells, rice husk, etc.

Available industries: Heating, chemical, food, tobacco, textile, print and dyeing, feed, medicine, building materials, wine, hospital


SZL Series Wood Chip Pellet Boiler Introduction

The SZL series wood chip pellet boiler adopts a chain grate structure, which efficiently burns biomass fuels such as wood chips and pellets, effectively reducing operational costs while meeting stringent environmental standards. The SZL series wood chip pellet boiler features a double-drum horizontal design, equipped with a large furnace design and efficient heat transfer tubes to ensure high thermal efficiency. Additionally, the independent air chamber design of the boiler ensures more complete fuel combustion and environmentally friendly emissions, with particulate matter and NOx emissions far below national standards. The SZL series wood chip pellet boiler is also equipped with ultra-low water level electrode protection, interconnected with the forced and induced draft fans, ensuring the safe water level during operation.

SZL Series Wood Chip Pellet Boiler Features

High Efficiency and Energy Saving: The SZL series wood chip pellet boiler features a water-cooled wall structure with densely arranged tubes in the furnace, paired with a customized boiler system that offers a large radiation area, reducing operational costs.

Ease of Operation: The advanced control system of the SZL series wood chip pellet boiler automates fuel supply, ash discharge, and slag discharge, providing a high level of operational automation.

Complete Fuel Combustion: The chain grate and independent air chamber design of the SZL series wood chip pellet boiler ensure complete fuel combustion.

Strong Adaptability: The SZL series wood chip pellet boiler is suitable for various biomass fuels, including wood pellets, straw pellets, rice husks, and more. With a wide range of fuel sources, it offers flexible operating costs and meets the needs of different industries.

SZL Series Wood Chip Pellet Boiler Specification

Model Rated thermal power (t/h) Rated working pressure (MPa) Rated steam temperature (℃) Maximum transport dimension (m)
SZL6-1.25-SCⅢ 6 1.25 194 6.20×2.80×3.65
7.20×2.60×2.80
SZL6-1.6-SCⅢ 6 1.6 204 6.20×2.80×3.65
7.20×2.60×2.80
SZL6-2.5-SCⅢ 6 2.5 225 6.20×2.80×3.65
7.20×2.60×2.80
SZL8-1.25-SCⅢ 8 1.25 194 7.10×3.52×3.65
7.80×3.10×2.80
SZL8-1.6-SCⅢ 8 1.6 204 7.10×3.52×3.65
7.80×3.10×2.80
SZL8-2.5-SCⅢ 8 2.5 225 7.10×3.52×3.65
7.80×3.10×2.80
SZL10-1.25-SCⅢ 10 1.25 194 7.90×3.52×3.65
8.40×3.10×2.80
SZL10-1.6-SCⅢ 10 1.6 204 7.90×3.52×3.65
8.40×3.10×2.80
SZL10-2.5-SCⅢ 10 2.5 225 7.90×3.52×3.65
8.40×3.10×2.80
SZL12-1.25-SCⅢ 12 1.25 194 8.80×3.52×3.65
8.40×3.10×2.80
SZL12-1.6-SCⅢ 12 1.6 204 8.80×3.52×3.65
8.40×3.10×2.80
SZL12-2.5-SCⅢ 12 2.5 225 8.80×3.52×3.65
8.40×3.10×2.80
SZL15-1.25-SCⅢ 15 1.25 194 9.60×3.20×3.65
8.30×3.30×3.00
SZL15-1.6-SCⅢ 15 1.6 204 9.60×3.20×3.65
8.30×3.30×3.00
SZL15-2.5-SCⅢ 15 2.5 225 9.60×3.20×3.65
8.30×3.30×3.00
SZL20-1.25-SCⅢ 20 1.25 194 10.65×3.28×3.60
9.30×3.81×2.80
SZL20-1.6-SCⅢ 20 1.6 204 10.65×3.28×3.60
9.30×3.81×2.80
SZL20-2.5-SCⅢ 20 2.5 225 10.65×3.28×3.60
9.30×3.81×2.80
SZL25-1.25-SCⅢ 25 1.25 194 11.65×3.80×3.60
9.30×3.81×3.00
SZL25-1.6-SCⅢ 25 1.6 204 11.65×3.80×3.60
9.30×3.81×3.00
SZL25-2.5-SCⅢ 25 2.5 225 11.65×3.80×3.60
9.30×3.81×3.00
SZL30-1.25-SCⅢ 30 1.25 194 10.00×3.36×3.60
SZL30-1.6-SCⅢ 30 1.6 204 10.00×3.36×3.60
SZL30-2.5-SCⅢ 30 2.5 225 10.00×3.36×3.60
SZL35-1.25-SCⅢ 35 1.25 194 10.00×3.65×3.85
SZL35-1.6-SCⅢ 35 1.6 204 10.00×3.65×3.85
SZL35-2.5-SCⅢ 35 2.5 225 10.00×3.65×3.85
