WNS Series Asme Steam Boiler

ZOZEN Asme Steam Boiler

Product thermal capacity: 1 – 20 t/h

Working pressure: 0.7-2 MPa

Available fuel: Natural gas, coke oven gas, biogas, diesel, heavy oil, light oil, crude oil, etc.

Available industries: Heat supplying, chemical, food, textile, printing and dyeing, cigarettes and tobacco, fodder, pharmacy, building materials, brewery, rubber, hospital etc.

WNS Series Asme Steam Boiler Introduction

The WNS series ASME steam boiler is a high-efficiency steam boiler that complies with the standards of the American Society of Mechanical Engineers (ASME). It is specifically designed for industries that have high steam supply demands in their production processes. The WNS series ASME steam boiler adopts a horizontal three-pass structure, providing excellent thermal efficiency and stable steam output. It is widely used in industries such as chemicals, food, pharmaceuticals, and papermaking.

The core advantage of the WNS series ASME steam boiler lies in its efficient combustion system and scientifically designed heat exchange system, which can effectively reduce fuel consumption while maximizing thermal efficiency. The boiler is equipped with advanced burners and an automatic control system, ensuring precise control of the fuel-to-air ratio during operation, reducing energy waste, and significantly lowering emissions.

Additionally, the WNS series ASME steam boiler places a strong emphasis on safety and environmental protection. Its design meets the strict requirements of ASME and includes a comprehensive safety protection system, such as pressure sensors, over-temperature protection, and low water level protection, ensuring the boiler’s safety and reliability during high-intensity operation. The boiler’s flue gas temperature control system effectively reduces heat loss and environmental pollution, meeting modern environmental protection standards.

WNS Series Asme Steam Boiler Advantages

High Efficiency and Energy Saving: The WNS series ASME steam boiler uses an advanced three-pass design and optimized combustion system, effectively improving thermal efficiency, reducing energy consumption, and lowering operating costs, helping enterprises achieve energy-saving and emission reduction goals.

Stable and Reliable Steam Supply: This series of boilers provides stable steam output that can meet the high demands of various industrial production processes, ensuring continuous and stable operation of the production line and preventing production interruptions caused by insufficient steam supply.

Compliance with International Safety Standards: The WNS series boiler is designed in strict accordance with ASME standards, equipped with a comprehensive safety protection system, including over-temperature protection, low water level protection, and pressure sensors, ensuring the safety and reliability of the boiler during high-load operation.

Environmentally Friendly Design: The boiler is equipped with a high-efficiency burner and flue gas temperature control system, which effectively reduces emissions and heat loss, meets modern environmental protection requirements, reduces environmental pollution, and helps businesses enhance their green production image.

WWNS Series Asme Steam Boiler Specification

Model Rated steam capacity (t/h) Rated working pressure (MPa) Rated steam temperature (℃) Maximum transport weight (t) Maximum transport dimension (m)
WNS1-0.7-Q(Y) 1 0.7 170 4.5 3.25×1.80×2.00
WNS1-1.0-Q(Y) 1 1 184 4.5 3.25×1.80×2.00
WNS1.5-1.0-Q(Y) 1.5 1 184 7 3.65×2.05×2.45
WNS1.5-1.25-Q(Y) 1.5 1.25 194 7 3.65×2.05×2.45
WNS2-1.0-Q(Y) 2 1 184 9 4.60×2.20×2.60
WNS2-1.25-Q(Y) 2 1.25 194 9 4.60×2.20×2.60
WNS3-1.0-Q(Y) 3 1 184 11.5 5.35×2.40×2.80
WNS3-1.25-Q(Y) 3 1.25 194 11.5 5.35×2.40×2.80
WNS4-1.25-Q(Y) 4 1.25 194 15 5.00×2.60×2.95
WNS4-1.6-Q(Y) 4 1.6 204 15 5.00×2.60×2.95
WNS5-1.25-Q(Y) 5 1.25 194 18 5.55×2.658×3.20
WNS5-1.6-Q(Y) 5 1.6 204 18 5.55×2.658×3.20
WNS6-1.25-Q(Y) 6 1.25 194 19.5 5.93×2.80×3.20
WNS6-1.6-Q(Y) 6 1.6 204 19.5 5.93×2.80×3.20
WNS8-1.25-Q(Y) 8 1.25 194 25 7.00×2.80×3.25
WNS8-1.6-Q(Y) 8 1.6 204 25 7.00×2.80×3.25
WNS10-1.25-Q(Y) 10 1.25 194 27.5 7.65×2.80×3.25
WNS10-1.6-Q(Y) 10 1.6 204 27.5 7.65×2.80×3.25
WNS15-1.25-Q(Y) 15 1.25 194 40 7.95×3.50×3.75
WNS15-1.6-Q(Y) 15 1.6 204 40 7.95×3.50×3.75
WNS20-1.25-Q(Y) 20 1.25 194 52 8.55×3.90×4.15
WNS20-1.6-Q(Y) 20 1.6 204 52 8.55×3.90×4.15
