WNS Series Condensing Oil Boiler
Product thermal capacity: 1 – 20 t/h
Working pressure: 0.7-2 MPa
Available fuel: Natural gas, coke oven gas, biogas, diesel, heavy oil, light oil, crude oil, etc.
Available industries: Heat supplying, chemical, food, textile, printing and dyeing, cigarettes and tobacco, fodder, pharmacy, building materials, brewery, rubber, hospital etc.
WNS Series Condensing Oil Boiler Introduction
The WNS series condensing oil boiler adopts advanced condensing technology, which recovers latent heat from flue gases, significantly improving thermal efficiency and reducing energy consumption. The main features of the WNS series condensing oil boiler are its efficient heat exchange system and precise control technology. The boiler’s flue gas condensing system effectively recovers heat from high-temperature flue gases, enabling its thermal efficiency to reach over 98%, greatly reducing fuel consumption.
The design of the WNS series condensing oil boiler also focuses on safety and stability, equipped with multiple safety protection devices, including automatic protection features such as over-temperature, low water, and over-pressure, ensuring safe and reliable operation.
Additionally, through the integration with an intelligent control system, the WNS series condensing oil boiler allows real-time monitoring of the boiler’s operating status, optimizing the combustion process, further improving energy efficiency, and reducing operational costs.
WNS Series Condensing Oil Boiler Advantages
High Efficiency and Energy Saving: The WNS series condensing oil boiler uses condensing technology to recover latent heat from flue gases, with a thermal efficiency of over 98%. Compared to traditional boilers, it significantly improves fuel utilization, reduces energy consumption, and helps users save on operating costs.
Excellent Environmental Performance: With its advanced condensing design, the WNS series condensing oil boiler effectively reduces harmful gas emissions, helping enterprises achieve a more efficient and environmentally friendly production process.
Intelligent Control System: The WNS series condensing oil boiler is equipped with an advanced intelligent control system that can monitor the boiler’s operating status in real time, automatically adjust the combustion process, and ensure stable and efficient operation. Users can easily operate and manage the boiler through a digital interface, ensuring safe and energy-saving performance.
Safety and Reliability: The WNS series condensing oil boiler is designed with a focus on safety, featuring multiple protection mechanisms such as over-temperature, over-pressure, and low-water protection. These ensure high safety during operation. Automatic alarms and shutdown functions promptly respond to abnormal conditions, safeguarding operators’ safety.
WNS Series Condensing Oil Boiler Specification
| Model | Rated steam capacity (t/h) | Rated working pressure (MPa) | Rated steam temperature (℃) | Maximum transport weight (t) | Maximum transport dimension (m) |
| WNS1-0.7-Q(Y) | 1 | 0.7 | 170 | 4.5 | 3.25×1.80×2.00 |
| WNS1-1.0-Q(Y) | 1 | 1 | 184 | 4.5 | 3.25×1.80×2.00 |
| WNS1.5-1.0-Q(Y) | 1.5 | 1 | 184 | 7 | 3.65×2.05×2.45 |
| WNS1.5-1.25-Q(Y) | 1.5 | 1.25 | 194 | 7 | 3.65×2.05×2.45 |
| WNS2-1.0-Q(Y) | 2 | 1 | 184 | 9 | 4.60×2.20×2.60 |
| WNS2-1.25-Q(Y) | 2 | 1.25 | 194 | 9 | 4.60×2.20×2.60 |
| WNS3-1.0-Q(Y) | 3 | 1 | 184 | 11.5 | 5.35×2.40×2.80 |
| WNS3-1.25-Q(Y) | 3 | 1.25 | 194 | 11.5 | 5.35×2.40×2.80 |
| WNS4-1.25-Q(Y) | 4 | 1.25 | 194 | 15 | 5.00×2.60×2.95 |
| WNS4-1.6-Q(Y) | 4 | 1.6 | 204 | 15 | 5.00×2.60×2.95 |
| WNS5-1.25-Q(Y) | 5 | 1.25 | 194 | 18 | 5.55×2.658×3.20 |
| WNS5-1.6-Q(Y) | 5 | 1.6 | 204 | 18 | 5.55×2.658×3.20 |
| WNS6-1.25-Q(Y) | 6 | 1.25 | 194 | 19.5 | 5.93×2.80×3.20 |
| WNS6-1.6-Q(Y) | 6 | 1.6 | 204 | 19.5 | 5.93×2.80×3.20 |
| WNS8-1.25-Q(Y) | 8 | 1.25 | 194 | 25 | 7.00×2.80×3.25 |
| WNS8-1.6-Q(Y) | 8 | 1.6 | 204 | 25 | 7.00×2.80×3.25 |
| WNS10-1.25-Q(Y) | 10 | 1.25 | 194 | 27.5 | 7.65×2.80×3.25 |
| WNS10-1.6-Q(Y) | 10 | 1.6 | 204 | 27.5 | 7.65×2.80×3.25 |
| WNS15-1.25-Q(Y) | 15 | 1.25 | 194 | 40 | 7.95×3.50×3.75 |
| WNS15-1.6-Q(Y) | 15 | 1.6 | 204 | 40 | 7.95×3.50×3.75 |
| WNS20-1.25-Q(Y) | 20 | 1.25 | 194 | 52 | 8.55×3.90×4.15 |
| WNS20-1.6-Q(Y) | 20 | 1.6 | 204 | 52 | 8.55×3.90×4.15 |
