YQW Series Industrial Thermal Fluid Heater

ZOZEN Industrial Thermal Fluid Heater

Product Thermal Capacity: 1400-14000 KW

Working Pressure:0.8-1.0 MPA

Available Fuel: Natural gas, coke oven gas, bio-gas, liquefied petroleum gas, diesel, heavy oil, light oil, crude oil

Available Industries: Petroleum, chemical, chemical fiber, pharmaceutical, textile printing and dyeing, building materials, wood processing, vegetable oil processing and other industries

Industrial Thermal Fluid Heater Introduction

The YQW series industrial thermal fluid heater is widely used in industries such as chemicals, petroleum, pharmaceuticals, food processing, and textiles. It uses high-temperature thermal oil as the heat transfer medium and provides stable and reliable high-temperature heat through efficient combustion technology and an optimized heat exchange system, meeting the heating needs of various industrial production processes. The YQW series industrial thermal fluid heater is equipped with an advanced automatic control system, allowing precise temperature control to ensure the safety and stability of the heat transfer oil during long-term operation at high temperatures. Additionally, this series of boilers adopts highly efficient burners and combustion optimization design, achieving a combustion efficiency of over 92%, significantly reducing energy consumption and emissions. It complies with national environmental protection standards, helping enterprises achieve green production. Furthermore, the YQW series industrial thermal fluid heater features a compact structure, simple operation, and easy maintenance.

Industrial Thermal Fluid Heater Advantages

High-Temperature Operation: The YQW series industrial thermal fluid heater provides high-temperature heat, making it suitable for processes that require high-temperature heating.

High Thermal Efficiency: The YQW series industrial thermal fluid heater uses high-quality thermal oil as the heat transfer medium, ensuring high thermal efficiency, energy savings, and environmental protection.

Stable Operation: The YQW series industrial thermal fluid heater is equipped with an advanced control system that automatically adjusts combustion parameters to maintain stable operation of the heater.

Multiple Safety Protections: The YQW series industrial thermal fluid heater is equipped with various safety protection devices to ensure safe and reliable operation of the equipment.

Industrial Thermal Fluid Heater Specification

Model Rated thermal power (KW) Rated thermal power (×104 kcal/h) Rated outlet oil temperature (°C) Rated working pressure (Mpa) Maximum transport dimensions (m)
YQ(Y)W-1400Q(Y) 1400 120 320 0.8 4.55×2.05×2.60
YQ(Y)W-1800Q(Y) 1800 160 320 0.8 4.95×2.15×2.70
YQ(Y)W-2100Q(Y) 2100 180 320 0.8 4.95×2.40×3.00
YQ(Y)W-2400Q(Y) 2400 200 320 0.8 5.40×2.40×3.00
YQ(Y)W-2800Q(Y) 2800 240 320 0.8 6.10×2.60×3.10
YQ(Y)W-3500Q(Y) 3500 300 320 0.8 6.90×2.60×3.10
YQ(Y)W-4200Q(Y) 4200 360 320 0.8 6.90×2.75×3.35
YQ(Y)W-4600Q(Y) 4600 400 320 0.8 6.90×2.92×3.55
YQ(Y)W-6000Q(Y) 6000 500 320 0.8 7.20×3.25×3.98
YQ(Y)W-7000Q(Y) 7000 600 320 0.8 7.80×3.40×4.10
YQ(Y)W-8200Q(Y) 8200 700 320 0.8 8.00×3.55×4.30
YQ(Y)W-9400Q(Y) 9400 800 320 0.8 9.15×3.70×4.60
YQ(Y)W-10500Q(Y) 10500 900 320 0.8 9.85×3.80×4.70
YQ(Y)W-12000Q(Y) 12000 1000 320 0.8 10.19×3.80×4.70
YQ(Y)W-14000Q(Y) 14000 1200 320 0.8 10.75×4.00×4.90
