SZL Series Biomass Fired 6 Ton Boiler Price

zozen 6 ton boiler price

Product thermal capacity: 6 t/h

Working pressure: 1-2.5 MPa

Available fuel: Biomass molding granules, wood chip, corn cob, saw dust, palm shells, rice husk, etc.

Available industries: Heating, chemical, food, tobacco, textile, print and dyeing, feed, medicine, building materials, wine, hospital

SZL Series Biomass fired 6 Ton Boiler Introduction

The SZL series biomass fired 6 ton steam boiler is a chain grate water tube boiler designed by ZOZEN Boiler based on advanced international technology and experience. It features a horizontal double-drum and vertical layout structure. The boiler consists of two major parts: the upper part is the heating surface and the lower part is the combustion equipment. The front of the boiler body is surrounded by water-cooled walls. The upper part is connected with drum and the lower part is connected with the header to form the combustion chamber, absorbing the radiation heat of the furnace. At the rear end, a convection tube bundle is arranged between the upper and lower drums. After the fuel is burned in the furnace, the high-temperature flue gas is swept across the convection tube bundle for the secondary return, then guided to a separately arranged economizer and finally enters the dust collector before being discharged through the chimney.

SZL Series Biomass fired 6 Ton Boiler Advantages

  • Broad Fuel Compatibility: Compatible with biomass pellets, rice husks, wood chips, corn cobs, sawdust etc.
  • Efficient Fuel Combustion: ZOZEN chain grate and independent air bin ensure thorough fuel combustion
  • Thermal Efficiency>86%: Densely arranged water-cooled walls in the furnace offer large radiation area
  • Simple Operation: Advanced controls automate fuel supply, ash removal, and slag discharge

SZL Series Biomass fired Boiler Specification

Model Rated thermal power (t/h) Rated working pressure (MPa) Rated steam temperature (℃) Maximum transport dimension (m)
SZL6-1.25-SCⅢ 6 1.25 194 6.20×2.80×3.65
7.20×2.60×2.80
SZL6-1.6-SCⅢ 6 1.6 204 6.20×2.80×3.65
7.20×2.60×2.80
SZL6-2.5-SCⅢ 6 2.5 225 6.20×2.80×3.65
7.20×2.60×2.80
SZL8-1.25-SCⅢ 8 1.25 194 7.10×3.52×3.65
7.80×3.10×2.80
SZL8-1.6-SCⅢ 8 1.6 204 7.10×3.52×3.65
7.80×3.10×2.80
SZL8-2.5-SCⅢ 8 2.5 225 7.10×3.52×3.65
7.80×3.10×2.80
SZL10-1.25-SCⅢ 10 1.25 194 7.90×3.52×3.65
8.40×3.10×2.80
SZL10-1.6-SCⅢ 10 1.6 204 7.90×3.52×3.65
8.40×3.10×2.80
SZL10-2.5-SCⅢ 10 2.5 225 7.90×3.52×3.65
8.40×3.10×2.80
SZL12-1.25-SCⅢ 12 1.25 194 8.80×3.52×3.65
8.40×3.10×2.80
SZL12-1.6-SCⅢ 12 1.6 204 8.80×3.52×3.65
8.40×3.10×2.80
SZL12-2.5-SCⅢ 12 2.5 225 8.80×3.52×3.65
8.40×3.10×2.80
SZL15-1.25-SCⅢ 15 1.25 194 9.60×3.20×3.65
8.30×3.30×3.00
SZL15-1.6-SCⅢ 15 1.6 204 9.60×3.20×3.65
8.30×3.30×3.00
SZL15-2.5-SCⅢ 15 2.5 225 9.60×3.20×3.65
8.30×3.30×3.00
SZL20-1.25-SCⅢ 20 1.25 194 10.65×3.28×3.60
9.30×3.81×2.80
SZL20-1.6-SCⅢ 20 1.6 204 10.65×3.28×3.60
9.30×3.81×2.80
SZL20-2.5-SCⅢ 20 2.5 225 10.65×3.28×3.60
9.30×3.81×2.80
SZL25-1.25-SCⅢ 25 1.25 194 11.65×3.80×3.60
9.30×3.81×3.00
SZL25-1.6-SCⅢ 25 1.6 204 11.65×3.80×3.60
9.30×3.81×3.00
SZL25-2.5-SCⅢ 25 2.5 225 11.65×3.80×3.60
9.30×3.81×3.00
SZL30-1.25-SCⅢ 30 1.25 194 10.00×3.36×3.60
SZL30-1.6-SCⅢ 30 1.6 204 10.00×3.36×3.60
SZL30-2.5-SCⅢ 30 2.5 225 10.00×3.36×3.60
SZL35-1.25-SCⅢ 35 1.25 194 10.00×3.65×3.85
SZL35-1.6-SCⅢ 35 1.6 204 10.00×3.65×3.85
SZL35-2.5-SCⅢ 35 2.5 225 10.00×3.65×3.85
