WNS Series Lpg Fired Steam Boiler

ZOZEN Lpg Fired Steam Boiler

Product thermal capacity: 1 – 20 t/h

Working pressure: 0.7-2 MPa

Available fuel: Natural gas, coke oven gas, biogas, diesel, heavy oil, light oil, crude oil, etc.

Available industries: Heat supplying, chemical, food, textile, printing and dyeing, cigarettes and tobacco, fodder, pharmacy, building materials, brewery, rubber, hospital etc.

WNS Series Lpg Fired Steam Boiler Introduction

The WNS series LPG fired steam boiler adopts a horizontal three-pass structure, with the boiler shell made of high-quality steel, offering excellent pressure resistance and corrosion resistance. The combustion system uses low-nitrogen combustion technology to ensure efficient combustion while reducing NOx emissions, meeting stringent environmental standards. The WNS series LPG fired steam boiler features high thermal efficiency, ease of operation, and a long service life, making it an indispensable piece of equipment in modern industrial production. With a precise automatic control system, the boiler can achieve remote monitoring and intelligent management, significantly improving work efficiency and reducing labor costs and maintenance difficulty.

WNS Series Lpg Fired Steam Boiler Advantages

High-efficiency combustion and energy-saving: The WNS series LPG fired steam boiler uses advanced low-nitrogen combustion technology and a three-pass structure, greatly improving combustion efficiency and effectively reducing energy consumption.

Strong environmental performance: The WNS series LPG fired steam boiler’s low NOx emission design complies with national environmental protection standards, reducing environmental pollution.

Automated control system: The WNS series LPG fired steam boiler is equipped with an intelligent control system, enabling real-time monitoring of the boiler’s operating status, automatic adjustment, and fault warning.

Long lifespan and high reliability: The WNS series LPG fired steam boiler, with high-quality materials and precision design, ensures long-term stable operation, low maintenance requirements, and a long service life.

WWNS Series Lpg Fired Steam Boiler Specification

Model Rated steam capacity (t/h) Rated working pressure (MPa) Rated steam temperature (℃) Maximum transport weight (t) Maximum transport dimension (m)
WNS1-0.7-Q(Y) 1 0.7 170 4.5 3.25×1.80×2.00
WNS1-1.0-Q(Y) 1 1 184 4.5 3.25×1.80×2.00
WNS1.5-1.0-Q(Y) 1.5 1 184 7 3.65×2.05×2.45
WNS1.5-1.25-Q(Y) 1.5 1.25 194 7 3.65×2.05×2.45
WNS2-1.0-Q(Y) 2 1 184 9 4.60×2.20×2.60
WNS2-1.25-Q(Y) 2 1.25 194 9 4.60×2.20×2.60
WNS3-1.0-Q(Y) 3 1 184 11.5 5.35×2.40×2.80
WNS3-1.25-Q(Y) 3 1.25 194 11.5 5.35×2.40×2.80
WNS4-1.25-Q(Y) 4 1.25 194 15 5.00×2.60×2.95
WNS4-1.6-Q(Y) 4 1.6 204 15 5.00×2.60×2.95
WNS5-1.25-Q(Y) 5 1.25 194 18 5.55×2.658×3.20
WNS5-1.6-Q(Y) 5 1.6 204 18 5.55×2.658×3.20
WNS6-1.25-Q(Y) 6 1.25 194 19.5 5.93×2.80×3.20
WNS6-1.6-Q(Y) 6 1.6 204 19.5 5.93×2.80×3.20
WNS8-1.25-Q(Y) 8 1.25 194 25 7.00×2.80×3.25
WNS8-1.6-Q(Y) 8 1.6 204 25 7.00×2.80×3.25
WNS10-1.25-Q(Y) 10 1.25 194 27.5 7.65×2.80×3.25
WNS10-1.6-Q(Y) 10 1.6 204 27.5 7.65×2.80×3.25
WNS15-1.25-Q(Y) 15 1.25 194 40 7.95×3.50×3.75
WNS15-1.6-Q(Y) 15 1.6 204 40 7.95×3.50×3.75
WNS20-1.25-Q(Y) 20 1.25 194 52 8.55×3.90×4.15
WNS20-1.6-Q(Y) 20 1.6 204 52 8.55×3.90×4.15
